SPF-7090 SKYLIGHT
PROTECTION FILM
Superior Protection, Natural Light, Sustainable Comfort
Superior Protection Natural Light Sustainable Comfort
Your building’s skylight is more than just a design feature—it’s a vital element that enhances natural lighting, aesthetics, and energy efficiency. However, it is constantly exposed to challenges such as falling debris, harsh weather, and harmful UV rays.
With SHUZELL’s SPF-7090 Skylight Protection Film, you can safeguard your skylight glass panels against damage while maintaining optimal clarity, light transmission, and thermal comfort. Experience long-lasting protection and sustainability without compromising your building’s architectural elegance or functionality.
Why Choose SPF-7090?
Our SPF-7090 delivers advanced protection tailored for architectural skylight glass panels, ensuring enhanced durability and functionality.
Crafted from premium materials, including grade A Thermoplastic Polyurethane (TPU) from BASF SE (Germany) and a pressure-sensitive adhesive from Ashland Inc. (USA), this film combines exceptional performance with eco-friendly benefits. Designed to preserve aesthetics while minimizing potential damage, SPF-7090 is your go-to solution for sustainable skylight protection and energy efficiency.
Crafted from premium materials, including grade A Thermoplastic Polyurethane (TPU) from BASF SE (Germany) and a pressure-sensitive adhesive from Ashland Inc. (USA), this film combines exceptional performance with eco-friendly benefits. Designed to preserve aesthetics while minimizing potential damage, SPF-7090 is your go-to solution for sustainable skylight protection and energy efficiency.
Key Features & Benefits
Light Sky-Blue Tint
Provides clear, aesthetically pleasing views while harmonizing with the natural sky.
High Visible Light Transmission (VLT)
Maintains natural brightness, reducing the need for artificial lighting.
Low Internal & External Reflectance (VLR)
Prevents night glare and minimizes urban light pollution.
Superior Heat Rejection (High IRR & TSER)
Blocks at least 90% infrared heat, ensuring a cooler indoor environment.
99% UV Rejection
Protects interiors from fading and shields occupants from harmful UV rays.
High Durability
Resists impacts, abrasions, stains, and harsh weather conditions.
Self-Healing Technology
Repairs minor scratches, ensuring long-term aesthetics and performance.
Hydrophobic & Oleophobic Coating
Repels water, oils, and dirt for easy maintenance and a spotless appearance.
Eco-Friendly Material
Crafted from 100% recyclable and biodegradable TPU for sustainable architecture.
PRODUCT SPECS & FEATURES
| Film Thickness (Mil/Micron) | 8 Mil (200 Micron) | ||||
|---|---|---|---|---|---|
| Color | Light Sky Blue | ||||
| Visible Light Tranmission (%) | 70% | ||||
| Infrared Rejection (%) | 90% | ||||
| Total Solar Energy Rejected (%) | 51% | ||||
| Ultraviolet Rejection (%) | >99% | ||||
| Tensile Strength | >20MPa (>204kg/cm2) | ||||
| Elongation at Break (%) | >180% | ||||
| Peel Strength | >75n/cm2 (7.65kg/cm * 10^4/2) | ||||
| Max Temperature | >110℃ | ||||
| Stone Chip Resistance | SAE J400 | ||||
| Chemical Resisrance | >72 hours soaked with 10% sulfuric acid | ||||
| Heat Resistance | >24 hours under 110℃ & 100% RH | ||||
| Weathering Resistance | >100 hours (QUV-B 313) | ||||
| Warranty | 5 years against delaminating, peeling, bubbling from adhessive failure |
||||
